CRG INTERCOOLER UPGRADES

$1300

PWR Racer Series Core + $410 Extr

(Install / Postage Extra)

Suits Navara NP300 Single and Twin Turbo 2015 onwards

   - Available for standard and 2" body lift

   - Intake temps improved by up to 40 degree in

extreme environments

   - Plug and play for a relatively easy DIY home install with basic tools

We are the ONLY company that offer a hot pipe for both single and twin turbo model

Currently we have an est. 6 - 8 week wait on all intercooler kits due to a backlog of orders through the Covid-19 pandemic period and continuation.

To secure your intercooler kit, we ask for a $500 deposit to lock in the next unit from the PWR production line then we can organise the final payment prior to shipping or at the time of fitting.

(Unprecedented Covid 19 delays / Change of mind cancelations may occur in loss of deposit or restocking fee)

Available to suit standard and 2 inch body lift. Make sure to stipulate if you have a lift at the time of ordering other wise a non body lift kit will not fit.

At the time of writing we are the ONLY company that offer a hot pipe for both single and twin turbo models.

We developed the dual 'o' ring hot pipe for the single turbo hot pipe.

Please let us know your model as the twin turbo hot pipe is not the same as the single.

From day dot of owning his own NP300, Chris couldn't handle the factory intercoolers lacking ability to cool the intake air temperature. Within weeks of owning Chris developed his own relocation kit to move the factory intercooler from down low behind the factory bash plates to up behind the main grill.

Chris worked with PWR to set a custom size for a PWR core and custom CRG Only end tanks to suit the application and maximise the size of the core and airflow through the grill..... with one major difference to any other kit.  It had to stay high enough to maximise flow, but allow room for a winch cradle inside the front bumper bar.... which you can see on the other 4X4 page, also suits most aftermarket bull bars and winch installs. CRGs on going development has led to 5 revisions of the piping kit that comes in the relocation. Designed for unmatched reliability and flow, 100% compatible with factory connections using our own custom CNC billet aluminium couplers  diesel specific high wear resistant seals, high quality silicon joiners and world class hose clamps.

Through our R&D process we can proudly say that we developed the first dual 'o' ring hot pipe for the single turbo RX owners to be able to also offer them the same quality kit as their twin turbo big brothers.

The PWR intercooler is engineered to increase power and fuel economy in your Navara by reducing intake temps and maintaining the low temps though all driving environments.

With the factory intercooler it is very common for the intake temps to exceed 100 degree C in even medium load environments, with our upgrade using the PWR 68mm core relocated we have seen a maximum average of 15 degree over ambient which has a far superior recovery rate than others we have tested.

- Australian engineered & manufactured

- Custom CNC billet aluminium couplers

- CNC machined billet aluminium outlets used throughout with unique ribbed design helps eliminate hose blow-off issues seen on other kits.

- 5-Ply Silicone hoses

- World Class JCS Hi Grip Stainless Steel Clamps

- Full colour fitting instructions are provided for both the intercooler and pipe kit install taking approx 3 hours to fit DIY



JCS HI-GRIP 304 STAINLESS (A2) CLAMPS

Hi-Grip stainless steel worm drive hose clips have become the industry standard for demanding applications throughout the world due to their exceptional quality and performance. Used as a standard requirement for the World Rally Championship and World Rally Cross.

Made entirely from 18/8 marine quality stainless steel and with Lloyds Register Approval, they are ideal for salt water and other highly corrosive environments. These clamps out last, out perform any clamp we have seen.  Please do not look at them and think a T bolt style clamp is better.  Quite simply you will be wrong in making that assumption, these clamps have over triple the clamping pressure of any other clamps we have used.

PWR Performance Products are making full use of the laws of physics, developing several of the most efficient intercoolers in the world. PWR use a revolutionary seamless rounded leading edge tube design throughout the manufacturing process. These tubes have an integrated internal fin with a straight through design, which improves heat transfer for less pressure drop, resulting in higher flow and reduced lag time. PWR intercoolers are individually hand manufactured using 12 FPI (fins per square inch) and can be custom designed by in house design division or simply just replace your current OEM system for better flow and performance.

PWR Air to Air Intercooler Features

- Low restriction internal turbulators

- Leading edge tube wall thickness is efficient for strength

- Light weight

- World class TIG welding

- State of the art controlled atmosphere brazing process

- Race and street proven performance

- Hi-tech CAD design division

- Pressured tested and guaranteed
